Allen-Bradley 1756-OA16

Allen-Bradley 1756-OA16 | 16-Channel AC Output Module for ControlLogix Systems

Overview

The Allen-Bradley 1756-OA16 is a 16-channel AC digital output module designed for use with ControlLogix systems. It provides reliable switching of 120/240V AC loads, making it suitable for a wide range of industrial applications including lighting, solenoids, contactors, and other AC-powered actuators.

With built-in status indicators, overvoltage protection, and integration into Studio 5000 Logix Designer, the 1756-OA16 offers efficient control and monitoring of AC output devices across your automation platform.

Key Features

• 16 AC Output Channels – Controls devices powered by 120V or 240V AC

• High-Density Output – Compact module for space-constrained panels

• Triac-Based Switching – Reliable for resistive and inductive loads

• Per-Channel Status LEDs – Quick visual diagnostics

• Overload and Overvoltage Protection – Enhanced durability and safety

• Integrated with Studio 5000 – Simple configuration and monitoring

• Hot-Swappable – Easy maintenance without shutting down the system

Technical Specifications

• Catalog Number: 1756-OA16

• Number of Outputs: 16

• Output Voltage Range: 74–265V AC (47–63 Hz)

• Output Current: 1.0 A per channel (max), 8 A total per module

• Isolation Voltage: 250V (continuous), basic insulation

• Backplane Current: ~150 mA @ 5.1V DC

• Minimum Load: 10 mA

• Response Time: <10 ms (typical)

• Mounting: ControlLogix chassis

• Operating Temperature: 0°C to +60°C

• Compatible Software: Studio 5000 Logix Designer

Applications

• Industrial Lighting Systems

• Contactor and Relay Control

• Solenoid and Valve Actuation

• Material Handling & Conveying Equipment

• Factory Automation Systems

Why Choose the 1756-OA16?

• Proven reliability for AC load control

• High channel count in a compact footprint

• Fully integrated with the ControlLogix architecture

Order Now

In stock and ready to ship globally.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
