Weintek MT8051iE | 4.3-Inch HMI Touchscreen

Weintek MT8051iE | Compact 4.3-Inch HMI Panel with Ethernet, Serial, and USB

Overview

The Weintek MT8051iE is a compact and cost-effective 4.3-inch HMI (Human Machine Interface) designed for industrial automation applications. Featuring a 480x272 TFT LCD, this unit offers Ethernet, RS-232/RS-485, and USB host ports, ensuring broad compatibility with various PLCs. Configured via the intuitive EasyBuilder Pro software, it's ideal for OEMs, system integrators, and control panel builders.

Key Features

• 4.3" TFT LCD Display – 480x272 resolution, 16.7M colors, LED backlight

• Resistive Touchscreen – 4-wire for accurate operator input

• Ethernet Communication – 10/100 Mbps for networking and remote access

• RS-232/RS-485 Serial Ports – Wide PLC protocol compatibility

• USB Host Port – For data logging and peripheral connectivity

• Built-in RTC – Real-time clock for time-stamped data

• Fanless Cooling Design – Silent operation with reduced maintenance

• NEMA4/IP65 Front Panel – Protection against dust and water

Technical Specifications

• Model: MT8051iE

• Display Size: 4.3 inches

• Resolution: 480 x 272 pixels

• Touch Panel: 4-wire resistive

• Processor: 32-bit RISC Cortex-A8 600MHz

• Memory: 128 MB Flash / 128 MB RAM

• Ethernet: 1 x 10/100 Base-T

• Serial Ports:

  • COM1: RS-232/RS-485 2W/4W

  • COM3: RS-485 2W

• USB Host: 1 x USB 2.0

• Power Input: 24V DC ±20%

• Power Consumption: 450 mA @ 24VDC

• Dimensions (WxHxD): 128 x 102 x 32 mm

• Panel Cutout: 119 x 93 mm

• Operating Temperature: 0°C to +45°C

• Mounting: Panel mount

• Protection Structure: NEMA4 / IP65 Compliant Front Panel

• Certifications: CE, cULus Listed

• Software: EasyBuilder Pro V6.06.02 or later

Applications

• Industrial Automation Systems

• PLC-Based Control Panels

• OEM Machine Interfaces

• SCADA & Data Logging Displays

Why Choose the MT8051iE?

• Compact and slim design for space-constrained applications

• Robust industrial design with flexible communication options

• Easy integration using free EasyBuilder Pro software

Order Now

In stock and available for global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
