Weintek cMT2109X2 | 10.1-Inch Capacitive Touch HMI

Weintek cMT2109X2 | High-Performance 10.1-Inch Smart HMI with Multi-Touch and Dual Ethernet

Overview

The Weintek cMT2109X2 is a next-generation 10.1-inch capacitive touch HMI designed for high-performance industrial and IIoT applications. Featuring a powerful quad-core processor, multi-touch screen, dual Gigabit Ethernet ports, and serial communication, it provides maximum flexibility for complex automation tasks. It also supports protocols like OPC UA, MQTT, Modbus TCP/IP, and SQL integration, making it ideal for smart manufacturing environments.

Key Features

• 10.1" Capacitive Touchscreen – 1280x800 resolution, supports multi-touch gestures

• Quad-Core Processor – High-speed processing for real-time control and display

• Dual Ethernet Ports – Enables network segmentation between OT and IT

• RS-232 & RS-485 (2W/4W) – Flexible PLC communication

• USB Host and SD Slot – Supports data logging and backup

• Built-In RTC – For timestamped alarms and logging

• Fanless Cooling Design – Quiet and maintenance-free

• NEMA4/IP65 Front Panel – Water and dust resistant

• EasyAccess 2.0 Compatible – Supports secure remote monitoring (license required)

Technical Specifications

• Model: cMT2109X2

• Display Type: 10.1” TFT LCD, 1280 x 800 resolution

• Touch Panel: Capacitive multi-touch

• CPU: ARM Cortex-A17 Quad-Core

• Memory: 4GB eMMC Flash / 1GB RAM

• Ethernet Ports: 2 x 10/100/1000 Mbps

• Serial Ports:

  • COM1: RS-232

  • COM2 & COM3: RS-485 (2W/4W)

• USB Host: 1 x USB 2.0

• SD Card Slot: SD/SDHC compatible

• Power Input: 24V DC ±20%

• Power Consumption: ~650 mA @ 24VDC

• Panel Cutout: 260 x 202 mm

• Dimensions (WxHxD): 271 x 213 x 36 mm

• Operating Temperature: 0°C to +50°C

• Mounting: Panel mount

• Front Panel Protection: IP65

• Software: EasyBuilder Pro

Applications

• Smart Factory HMIs

• Industrial IoT Gateways

• MES/SCADA Interfaces

• Machine Control Panels

• Remote Monitoring Stations

Why Choose the cMT2109X2?

• Modern, fast, and highly compatible with advanced protocols

• Dual Ethernet for network isolation and cloud integration

• Multi-touch UI for intuitive operator interaction

Order Now

In stock and available for immediate worldwide shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
