WAGO 750-402 – 4 DI 24 VDC, 3 ms High-Side Switching

Overview

The WAGO 750-402 is a 4-channel digital input module in the WAGO I/O System 750/753. It accepts 24 VDC input signals, using high-side switching with a 3 ms noise-rejection filter to guard against signal bounce. The module is electrically isolated between system and field sides, has per-channel LEDs for status indication, and is designed for compact DIN-rail usage with a slim 12 mm width.

Key Features

• Four digital input channels, 24 VDC

• High-side switching input characteristic

• Noise-rejection filter with 3 ms time constant

• LED status indicators for each input channel

• Electrical isolation (system vs field)

• Compact width (~12 mm) for space-efficient installation

• Uses CAGE-CLAMP® terminals for wiring reliability

Technical Specifications

Part Number: 750-402
Number of Digital Inputs: 4
Nominal Voltage (Field): 24 VDC (−25 % … +30 %)
Threshold for “Low” (0): −3 V … +5 VDC
Threshold for “High” (1): 15 V … 30 VDC
Input Filter Time: 3.0 ms
Typical Input Current per Active Channel: ~4.5 mA
Internal Current Consumption (5 V System Supply): ~7.5 mA
Isolation Voltage (System vs Field): 500 V
Internal Bit Width: 4 bits
Wire Connection: CAGE-CLAMP®
Conductor Size (Solid / Stranded): 0.08 … 2.5 mm² (AWG 28 … 14)
Wire Strip Length: 8 … 9 mm
Width: ≈ 12 mm
Height: ≈ 100 mm
Depth: ≈ 69.8 mm
Depth from Upper Edge of DIN-Rail: ≈ 62.6 mm
Operating Temperature: 0 °C … +55 °C
Storage Temperature: −40 °C … +85 °C
Protection Rating: IP20
Pollution Degree: 2

Applications

• Sensing 24 V field devices such as switches, proximity sensors in automation

• Use where some noise in signals is expected, needing filtering (3 ms)

• Compact I/O panels where space is constrained

• Applications that require reliable status indication per input

Why Choose the WAGO 750-402

• Solid noise suppression for clean signal detection

• High input voltage swing and margin ensure robustness

• Isolation ensures safety and minimize interference

• Slim module profile maximizes D-rail space

Order Now

The WAGO 750-402 is part of the WAGO I/O System 750 product line and is available for purchase. Ships worldwide.
