Siemens 6ED1055-1MM00-0BA2 | LOGO! Expansion Module – 4 Analog Inputs, 0–10V, 24V DC, IP20

Overview

The Siemens 6ED1055-1MM00-0BA2 is an analog input expansion module for the LOGO! 8 logic controller, adding four analog inputs to support 0–10V voltage signals. Designed for monitoring analog sensors and transducers in compact automation systems, this module is powered by 24V DC and fits neatly beside the main LOGO! CPU on a DIN rail.

Key Features

• Analog Inputs: 4 channels

• Input Range: 0–10V

• Resolution: 10 bits

• Input Type: Voltage (single-ended)

• Power Supply: 24V DC

• Connection Type: Screw terminals

• Mounting: DIN rail

• Protection Rating: IP20

• Status LEDs: Per input channel for diagnostics

Technical Specifications

• Part Number: 6ED1055-1MM00-0BA2

• Series: LOGO! 8

• Operating Voltage Range: 20.4 to 28.8 V DC

• Max Input Impedance: >100 kΩ

• Dimensions (W x H x D): Approx. 72 x 90 x 55 mm

• Weight: Approx. 160 g

• Operating Temperature: 0°C to +55°C

• Certifications: CE, UL, RoHS compliant

Applications

• Monitoring analog sensors (e.g., temperature, pressure, level)

• Small-scale building automation systems

• Energy management in residential and industrial applications

• Signal acquisition in educational labs and training systems

Why Choose the 6ED1055-1MM00-0BA2?

• Expand Analog Capabilities: Adds 4 AI to any LOGO! 8 system

• Versatile Integration: Compatible with standard 0–10V sensors

• Compact and Reliable: DIN rail mounting with robust housing

• Fast Installation: Simple wiring with screw terminals

• Siemens Quality: Trusted performance for small automation tasks

Order Now

The Siemens 6ED1055-1MM00-0BA2 LOGO! analog expansion module is available and ready for worldwide shipping.

Return to Siemens LOGO! Logic Module

Explore Siemens PLCs Family
