Siemens 3RT1056-6AP36

Siemens 3RT1056-6AP36 | SIRIUS Power Contactor

Overview:

The Siemens 3RT1056-6AP36 is a robust SIRIUS series power contactor designed for efficient switching of electric motors in industrial settings. Rated at 90 kW (125 HP) for 400 V AC systems, it supports operational currents up to 185 A. The contactor features a 220-240 V AC/DC coil and comes with 2 Normally Open (NO) and 2 Normally Closed (NC) auxiliary contacts, providing versatile control options. Its compact design and reliable performance make it ideal for various motor control applications.

Key Features:

• High Power Switching: Capable of handling motors up to 90 kW (125 HP) at 400 V, suitable for demanding industrial applications.
• Robust Current Capacity: Supports operational currents up to 185 A, ensuring reliable performance under heavy loads.
• Versatile Coil Operation: Equipped with a 220-240 V AC/DC coil, allowing flexibility in control voltage requirements.
• Auxiliary Contacts Included: Comes with 2 NO and 2 NC auxiliary contacts for expanded control and signaling capabilities.
• Compact and Durable Design: Engineered for space-saving installations without compromising on durability.

Technical Specifications:

• Product Type: SIRIUS Power Contactor
• Part Number: 3RT1056-6AP36
• Number of Poles: 3
• Motor Power Rating: 90 kW (125 HP) at 400 V
• Operational Current: 185 A (AC-3)
• Control Voltage: 220-240 V AC/DC
• Auxiliary Contacts: 2 NO + 2 NC
• Mounting Type: Base mounting with screw terminals
• Protection Rating: IP00 (intended for installation within an appropriate enclosure)
• Standards Compliance: Conforms to IEC 60947-4-1

Applications:

• Industrial Motor Control: Ideal for controlling large motors in manufacturing and processing plants.
• Pumping Systems: Ensures reliable operation of high-power pumps in water treatment and irrigation systems.
• HVAC Systems: Suitable for switching compressors and large fans in heating, ventilation, and air conditioning setups.
• Material Handling: Supports conveyors, hoists, and cranes requiring robust motor control solutions.

The Siemens 3RT1056-6AP36 SIRIUS Power Contactor offers a dependable and efficient solution for high-power motor switching applications, combining versatility with robust performance to meet the demands of modern industrial environments.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
