Semikron SKM40GD123D

Semikron SKM40GD123D

Overview

The Semikron SKM40GD123D is a single IGBT module rated at 40 A and 1200 V, designed for reliable and efficient power switching. Housed in a compact SEMITRANS 1 package, it features integrated diode and trench-field stop technology, making it ideal for applications with tight space and thermal constraints.

Key Features

• Collector-Emitter Voltage: 1200 V

• Continuous Collector Current: 40 A

• Low VCE(sat) for reduced conduction losses

• Built-in freewheeling diode

• Electrically isolated baseplate

• Compact SEMITRANS 1 package

• High switching speed and efficiency

• Screw terminal mounting

Technical Specifications

• Part Number: SKM40GD123D

• VCE: 1200 V

• IC: 40 A

• VCE(sat) (typical): ~2.0 V

• Isolation Voltage: ≥2500 V AC

• Mounting Type: Chassis

• Package: SEMITRANS 1

• Operating Temperature: –40 °C to +150 °C

• Integrated Diode: Yes

• Cooling: Conduction through baseplate

Applications

• Inverter systems

• Motor drives

• Industrial automation

• Power supplies

• UPS and energy storage systems

Why Choose the SKM40GD123D

• Compact and easy to install

• Reliable performance in mid-power systems

• Efficient thermal management

• Trusted quality from Semikron

Order Now

The Semikron SKM40GD123D IGBT module is available and ships worldwide.

Return to the Semikron IGBT Modules collection for more models, ratings, and configurations.

Explore the Power Electronics Components main category main category to discover diodes, thyristors, GTOs, MOSFETs, and other semiconductor solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
