SAMSUNG LMS700KF25

SAMSUNG LMS700KF25

Overview

The SAMSUNG LMS700KF25 is a 7.0-inch TFT LCD module developed for industrial, embedded, and Human-Machine Interface (HMI) systems. Offering 800×480 (WVGA) resolution with an LED backlight, it ensures excellent color reproduction, consistent brightness, and long-term reliability for demanding environments.

Key Features

• 7.0-inch TFT LCD panel

• WVGA resolution: 800×480

• LED backlight for energy efficiency and long lifespan

• High brightness and sharp visual performance

• Wide viewing angles for versatile mounting

• Robust and compact design for industrial integration

Technical Specifications

• SAMSUNG Code: LMS700KF25

• Display Size: 7.0"

• Resolution: 800×480 (WVGA)

• Display Type: TFT LCD

• Backlight: LED

• Brightness: 400 cd/m² (typical)

• Contrast Ratio: 600:1 (typical)

• Viewing Angle: 140° horizontal / 110° vertical

• Interface: RGB

• Operating Temperature: –20 °C to +70 °C

• Storage Temperature: –30 °C to +80 °C

Applications

• Industrial control and automation displays

• Embedded systems

• Human-Machine Interface (HMI) terminals

• Portable and diagnostic devices

• Process monitoring and instrumentation

Why Choose SAMSUNG LMS700KF25?

• Samsung TFT technology ensures superior visual clarity

• Energy-efficient LED backlight with long operational life

• Reliable and durable for industrial environments

• Ideal for embedded and HMI display applications

Order Now

Enhance your embedded and industrial solutions with the SAMSUNG LMS700KF25, a 7.0-inch TFT LCD display built for clarity, reliability, and long-term performance.

Return to Samsung Displays

Return to TFT Display Modules

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
