ABB S202-C16 | Miniature Circuit Breaker (MCB)

ABB S202-C16 | Miniature Circuit Breaker (MCB)

Overview

The ABB S202-C16 is a miniature circuit breaker (MCB) designed to offer reliable protection for electrical circuits in case of overloads or short circuits. With a C-curve characteristic, it is ideal for standard industrial, commercial, and residential applications where moderate inrush currents are expected. The S202-C16 provides an effective solution for safeguarding electrical installations and ensuring long-term system reliability.

Key Features

• C-curve: Suitable for circuits with moderate inrush currents such as lighting, heating systems, and small motors.
• Rated Current: 16 A, ensuring the breaker provides the appropriate protection for low- to medium-power circuits.
• Short Circuit Protection: Automatically trips in the event of a short circuit, preventing potential damage to the wiring and devices.
• Overload Protection: Trips when an overload condition is detected, protecting the circuit from overheating and potential fire hazards.
• Compact Design: The S202-C16 is space-efficient, making it ideal for installation in crowded electrical panels or distribution boards.
• Modular Design: Designed to be easily integrated into modular electrical systems, allowing for straightforward installations and maintenance.
• Tripping Mechanism: Instantaneous response for short circuit and overload protection, minimizing potential damage to connected devices.
• Temperature Range: Designed for reliable operation across a wide temperature range, providing consistent protection in varying environmental conditions.

Technical Specifications

• Model: S202-C16
• Type: Miniature Circuit Breaker (MCB)
• Rated Current: 16 A
• Rated Voltage: 230/400 V AC
• Number of Poles: 1-pole
• Curve Type: C-curve (for moderate inrush currents)
• Breaking Capacity: 6 kA
• Mounting: 35mm DIN rail
• Standards Compliance: IEC 60898
• Dimensions: 79mm (H) x 18mm (W) x 70mm (D)
• Tripping Mechanism: Thermomagnetic

Applications

• Residential: Used in residential electrical systems to protect lighting circuits, sockets, and household appliances.
• Commercial: Ideal for protecting electrical systems in small businesses, offices, and retail environments.
• Industrial: Suitable for moderate power circuits such as small motors, heating systems, and other equipment requiring standard protection.
• Power Distribution: Provides essential protection in distribution boards to safeguard circuits from overcurrent events.

The ABB S202-C16 is a reliable miniature circuit breaker designed to protect electrical circuits from short circuits and overloads. With its robust features and easy integration into modular systems, it ensures the safety and longevity of electrical installations in both residential and commercial environments.
