Allen-Bradley 193-EC2CB

Allen-Bradley 193-EC2CB

Overview

The Allen-Bradley 193-EC2CB is a solid-state E3 Plus electronic motor protection relay, designed to protect motors operating in the 5–25 amp full load current range. This Series B model features DeviceNet communication, internal ground fault detection, and PTC thermistor input. With 4 digital inputs and 2 relay outputs, it delivers advanced protection, diagnostics, and local control capability using DeviceLogix.

Key Features

• Full Load Current Range: 5–25A

• Inputs / Outputs: 4 discrete inputs (24V DC), 2 Form C relay outputs

• PTC Thermistor Input: Monitors motor winding temperature

• Internal Ground Fault Sensor: Detects low-level faults (1–5A range)

• Communication: DeviceNet (Series B), slave-only

• DeviceLogix: Local logic execution for faster control response

• Trip Class: Adjustable (Class 5–30)

• Mounting: Directly mounts to 100-C23 to C30 contactors

• Thermal Memory: Maintains heat model after power loss

• Phase Monitoring: Detects phase loss and imbalance

Technical Specifications

• Catalog Number: 193-EC2CB

• Series: B

• Current Range: 5–25A

• Discrete Inputs: 4 x 24V DC (sinking)

• Relay Outputs: 2 Form C contacts

• Control Voltage: 24V DC

• Power Consumption: Approx. 4.5 W

• Communication: DeviceNet, Group 2 slave

• Ground Fault Detection: Internal, low-level (1–5A)

• PTC Monitoring: Supported

• Operating Temperature: -20°C to +55°C

• Storage Temperature: -40°C to +85°C

• Protection Rating: IP1X

• Mounting Compatibility: 100-C23 to 100-C30 contactors

• Certifications: UL, CE, CSA, RoHS

Applications

• Intelligent protection for low- to mid-range motors

• Pump and fan applications with temperature monitoring

• OEM panels using DeviceNet architecture

• Industrial machines requiring localized diagnostics and fault response

• Motor circuits needing overload, PTC, and ground fault protection

Why Choose the 193-EC2CB

• Versatile Protection: Monitors overload, ground fault, thermistor, phase loss, and current imbalance

• Built-In Logic: DeviceLogix enables fast, local decisions without a PLC

• Seamless Integration: Mounts directly to contactors and connects via DeviceNet

• Compact and Efficient: Saves space and wiring in control panels

• Reliable Performance: Real-time diagnostics and adjustable trip classes

Order Now

The Allen-Bradley 193-EC2CB E3 Plus motor protection relay is available and ships worldwide.
