ABB OT100F3 | Molded Case Circuit Breaker (MCCB)

Overview

The ABB OT100F3 is a molded case circuit breaker (MCCB) offering reliable protection for overload and short circuit conditions in industrial and commercial electrical systems. With a 100A rated current, it ensures safe operation for circuits carrying high power loads. Featuring adjustable trip settings and a compact design, the OT100F3 is ideal for control panels, power distribution systems, and motor control centers. This MCCB is designed to withstand harsh industrial environments and offer long-term protection.

Key Features

• Model: ABB OT100F3
• Function: Molded case circuit breaker (MCCB) for overload and short circuit protection
• Rated Current: 100A
• Adjustable Trip Settings: Customizable protection for various system loads
• Breaking Capacity: Up to 36kA (at 415V)
• Thermal and Magnetic Protection: Provides reliable protection against overload and short circuit conditions
• Compact Design: Ideal for panel installations
• Long-Lasting Durability: Designed to perform reliably in demanding environments

Technical Information

• Rated Voltage: 400V AC
• Breaking Capacity: 36kA (at 415V)
• Tripping Type: Thermal-magnetic
• Mounting Type: DIN rail
• Operating Temperature: -5°C to 40°C
• Protection Class: IP20
• Weight: 3.1 kg

Applications

• Industrial Power Distribution: Protects circuits and equipment in factories, plants, and machinery
• Commercial Buildings: Safeguards electrical systems in offices, data centers, and retail spaces
• Motor Control Centers: Ideal for motor protection in automation and control systems
• HVAC Systems: Protects heating, ventilation, and air conditioning (HVAC) equipment

Benefits

• Reliable Protection: Provides protection against overload and short circuit conditions
• Customizable Settings: Adjustable trip settings for various loads and applications
• Compact and Efficient: Space-saving design ideal for panel installations
• Durable and Long-Lasting: Built to endure tough environments and offer consistent protection

The ABB OT100F3 is a molded case circuit breaker that offers superior protection for industrial and commercial electrical applications, ensuring reliable operation and safety.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
