Mitsubishi RX41C4-TS

Mitsubishi RX41C4-TS

Overview

The Mitsubishi RX41C4-TS is a versatile 4-channel analog output module for the MELSEC R Series PLC, providing high-resolution 16-bit outputs for voltage (0–10 V) or current (0–20 mA) signals. It also includes built-in temperature sensor support, making it ideal for closed-loop control, process automation, and analog-driven instrumentation systems.

Key Features

• Series: R Series PLC

• Output Channels: 4

• Output Type: Selectable voltage (0–10 V) or current (0–20 mA)

• Resolution: 16-bit DAC

• Temperature Input: Built-in sensor support

• Isolation: Channel-to-system isolation

• LED Diagnostics: Status indicators per channel

• Mounting: Base unit rack mounting

Technical Specifications

• Catalog Number: RX41C4-TS

• Channels: 4 analog output channels

• Voltage Output Range: 0–10 V DC

• Current Output Range: 0–20 mA

• Resolution: 16-bit (0.15 mV or 3 µA per step)

• Load Resistance: ≥ 2 kΩ (voltage), ≤ 600 Ω (current)

• Temperature Sensor Support: RTD/thermocouple type input (configurable)

• Output Accuracy: ±0.1% FS

• Isolation Voltage: 1500 VAC

• Operating Temperature: 0 °C to 55 °C

• Storage Temperature: –25 °C to 75 °C

• Dimensions: Approx. 90 × 87 × 40 mm

• Weight: ≈ 0.35 kg

• Certifications: CE, UL

Applications

• Process control (temperature, pressure, level)

• Servo/valve actuator control via analog signals

• Closed-loop control systems

• HMI or SCADA analog output

• OEM machine analog integration

Why Choose the RX41C4-TS

• High Precision: 16-bit outputs provide fine control

• Versatile Output: Select voltage or current to suit loads

• Temperature Integration: Onboard sensor input simplifies designs

• Diagnostic LEDs: Quick visual status per channel

• Seamless Integration: Directly mounts in R Series PLC racks

Order Now

The Mitsubishi RX41C4-TS analog output module is available and ships worldwide.

Return to the Mitsubishi MELSEC iQ-R Series collection for more options in this family.

Explore our full range of Mitsubishi MELSEC Programmable Controllers (PLC) to discover scalable automation solutions, from legacy MELSEC systems to next-generation PLCs designed for high performance, connectivity, and flexibility.
