Mitsubishi RX41C4

Mitsubishi RX41C4

Overview

The Mitsubishi RX41C4 is a high-precision 4-channel analog output module for the MELSEC R Series PLC, offering selectable voltage (0–10 V) or current (0–20 mA) outputs in 16-bit resolution. Designed for process control, it supports diverse industrial applications requiring accurate analog signal generation.

Key Features

• Series: R Series PLC

• Output Channels: 4 analog outputs

• Output Types: 0–10 V voltage or 0–20 mA current

• Resolution: 16-bit

• Isolation: Channel-to-system isolation

• Diagnostic LEDs: One per channel

• Mounting: Rack-mounted module

Technical Specifications

• Catalog Number: RX41C4

• Channels: 4 analog output channels

• Voltage Output Range: 0–10 V DC

• Current Output Range: 0–20 mA DC

• Resolution: 16-bit (≈0.15 mV or 0.3 µA steps)

• Load Requirements: ≥2 kΩ (voltage), ≤600 Ω (current)

• Output Accuracy: ±0.1% full scale

• Isolation Voltage: 1500 VAC

• Operating Temp: 0 °C to 55 °C

• Storage Temp: –25 °C to 75 °C

• Dimensions: Approx. 90 × 87 × 40 mm

• Weight: ≈0.35 kg

• Certifications: CE, UL, RoHS

Applications

• Proportional valve and actuator control

• Industrial process automation (temp/pressure/flow)

• Analog signal generation for HMI/SCADA integration

• Closed-loop industrial control systems

• Compact module for R Series PLC expansion

Why Choose the RX41C4

• Dual Output Capability: Switch between voltage and current outputs

• High Resolution: 16-bit DAC enables precise signal control

• True Isolation: Protects PLC from field electrical noise

• Visual Feedback: LED indicators aid quick diagnostics

• Seamless Integration: Fits directly into R Series racks

Order Now

The Mitsubishi RX41C4 analog output module is available and ships worldwide.

Return to the Mitsubishi MELSEC iQ-R Series collection for more options in this family.
