Mitsubishi QX10

Mitsubishi QX10

Overview

The Mitsubishi QX10 is a digital input module with 8 input points, designed for use with the Mitsubishi Q Series PLC platform. It accepts 24V DC sink or source signals and provides a compact and efficient solution for integrating discrete input signals in industrial automation environments.

Key Features

• Series: Q Series

• Number of Inputs: 8

• Input Type: Sink/source selectable

• Rated Input Voltage: 24V DC

• Response Time: 1.5 ms max

• Input Indicator: LED per channel

• Isolation: Photocoupler per input

• Terminal Type: Screw-type removable terminal block

• Mounting: DIN rail or base unit

Technical Specifications

• Catalog Number: QX10

• Input Points: 8

• Rated Input Voltage: 24V DC ±10%

• Input Current: 7 mA (approx.)

• Input Method: Sink/source

• Insulation Method: Photocoupler

• Response Time: 1.5 ms or less

• Ambient Temperature: 0°C to 55°C

• Protection Rating: IP20 (installed)

• Weight: ≈ 0.2 kg

• Certifications: CE, UL, RoHS

Applications

• Machine input signal capture

• Discrete input from sensors and switches

• Packaging machinery automation

• Conveyor systems and part tracking

• General-purpose I/O for Q Series systems

Why Choose the QX10

• Compact Size: Saves space in the control cabinet

• Reliable Input Processing: Suitable for high-speed signals

• Flexible Wiring: Sink/source compatibility

• Easy Integration: Designed for the Q Series platform

• Diagnostic LEDs: Quick visual feedback on input status

Order Now

The Mitsubishi QX10 digital input module is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
