Overview

The Mitsubishi QD70P4 is an 8-channel analog input module designed for the MELSEC-Q series PLC platform. It provides flexible input options for both voltage and current signals, delivering precise data acquisition and reliable performance in industrial automation and process monitoring applications.

Key Features

• 8 analog input channels

• Input types: Voltage (±10 V, 0–10 V) or Current (4–20 mA, 0–20 mA)

• High accuracy and resolution (≥ 12-bit)

• Individual channel range configuration

• Built-in diagnostics for signal faults

• Compact form factor for dense module configurations

• Seamless integration with MELSEC-Q systems

• Channel-to-channel isolation to reduce noise

Technical Specifications

• Catalog Number: QD70P4

• Number of Channels: 8

• Input Range:

  • Voltage: ±10 V, 0–10 V

  • Current: 4–20 mA, 0–20 mA

• Resolution: ≥ 12-bit

• Input Impedance:

  • Voltage: ≥ 100 kΩ

  • Current: 250 Ω

• Sample Rate: Typical update time per channel ≤ 4 ms

• Isolation: Channel-to-channel and to backplane

• Mounting: MELSEC-Q rack (e.g., Q65B)

• Operating Temperature: 0 °C to +55 °C

• Certifications: CE, UL, cUL, RoHS

Applications

• Process control (temperature, pressure, flow monitoring)

• Analog sensor integration in factory automation

• Building management systems and HVAC controls

• Lab and test instrumentation

• Distributed analog signal acquisition in automation racks

Why Choose the QD70P4

• Multi-range analog input in one module for flexibility

• High resolution and diagnostics ensure data accuracy

• Ideal for MELSEC-Q systems with compact form factor

• Reduces module count by combining multiple inputs

• Facilitates robust signal handling in noisy industrial settings

Order Now

The Mitsubishi QD70P4 analog input module is available and ships worldwide.
