Overview

The FX5-4AD-PT-ADP is an advanced analog input module designed for the MELSEC iQ-F Series. It supports four channels of platinum RTDs (Pt100/Pt1000), as well as standard voltage and current input signals, enabling precise analog data acquisition in industrial automation systems.

Key Features

• 4 analog input channels

• Supports:
  – Pt100 / Pt1000 (RTD)
  – 0–10 V DC
  – 0–20 mA DC

• High-accuracy 16-bit A/D conversion

• Built-in cold-junction compensation

• Simultaneous sampling on all channels

• DIN rail or panel mount compatible

• Diagnostic status LEDs

• Fully integrated with FX5U/FX5UC PLCs

Technical Specifications

• Model: FX5-4AD-PT-ADP

• Number of Channels: 4

• Supported Inputs:
  – Pt100 / Pt1000 RTD
  – Voltage: 0–10 V DC
  – Current: 0–20 mA DC

• A/D Resolution: 16-bit

• RTD Accuracy: Class A (IEC 751)

• Sampling Time: Approx. 5 ms per channel

• Load Impedance:
  – ≥10 kΩ (voltage)
  – ≤250 Ω (current)

• Isolation: Channel-to-channel

• Operating Temperature: 0 °C to +55 °C

• Power Supply: From FX5U PLC base unit

• Certifications: CE, UL, RoHS

Applications

• Temperature control with Pt100/Pt1000 sensors

• Analog process monitoring (pressure, flow, level)

• Automation in food, pharma, and packaging industries

• Data acquisition in OEM and laboratory setups

• Mixed-signal sensing in compact PLC systems

Why Choose the FX5-4AD-PT-ADP

• Combines RTD and analog signal input in one module

• Compact and easy to install

• High-precision 16-bit resolution

• Compatible with MELSEC iQ‑F architecture

• Excellent choice for multi-variable sensing

Order Now

The Mitsubishi FX5-4AD-PT-ADP is available and ships worldwide.

Return to the Mitsubishi FX5 Series PLC collection for more options in this family.
