Mitsubishi FX5-16EYT/ESS

Mitsubishi FX5-16EYT/ESS

Overview

The Mitsubishi FX5-16EYT/ESS is a 16-point digital output module designed for the FX5U and FX5UC PLC series. It features sink-type transistor outputs, supports 24V DC control, and uses spring clamp terminals for quick, tool-free wiring. This module is ideal for driving external actuators, solenoids, and relays in high-speed control systems.

Key Features

• Series: MELSEC iQ-F (FX5U/FX5UC)

• Output Points: 16

• Output Type: Transistor (sink)

• Rated Voltage: 24V DC

• Rated Current: 0.5A per point, 4.0A total

• Terminal Type: Spring clamp (ESS)

• Response Time: 0.2 ms or less

• Isolation: Photocoupler per channel

• Status Indication: LED for each output

• Mounting Method: DIN rail or direct panel

Technical Specifications

• Catalog Number: FX5-16EYT/ESS

• Rated Output Voltage: 24V DC

• Output Type: Sink-type transistor

• Number of Outputs: 16

• Output Current: 0.5A/point, 4.0A/module max

• Leakage Current: 0.1 mA or less

• ON Voltage Drop: 1.5V or less

• Wiring Method: Spring clamp terminals

• Isolation: Photocoupler

• Ambient Temperature: 0°C to 55°C

• Protection: Short-circuit and overcurrent detection via external devices

• Weight: ≈ 0.15 kg

• Certifications: CE, UL, cUL, RoHS

Applications

• Output control for relays, lamps, and solenoids

• High-speed machine automation

• Conveyor systems and robotic arms

• Packaging, sorting, and assembly lines

• General-purpose digital output in industrial PLC systems

Why Choose the FX5-16EYT/ESS

• Compact & Reliable: Space-saving design for tight panels

• Quick Wiring: Spring clamp terminal block simplifies installation

• High-Speed Output: Fast switching for real-time control

• Wide Compatibility: Seamless integration with FX5U/FX5UC PLCs

• Industrial Grade: Mitsubishi quality ensures long-term durability

Order Now

The Mitsubishi FX5-16EYT/ESS digital output module is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
