Overview

The Pilz 779211 PNOZ X3 is a high-performance safety relay, designed for monitoring emergency stops, safety gates, and light barriers in industrial automation. It ensures fail-safe switching and secure operation, meeting safety standards for machine and process protection.

With 3 normally open (NO), 1 normally closed (NC), and 1 semiconductor output (SO), the PNOZ X3 safety relay offers efficient control and monitoring of hazardous operations. Its DIN rail mounting and compact design make it ideal for safety-critical applications.

Key Features

• 3 NO Safety Contacts – Provides secure safety circuit integration
• 1 NC Monitoring Contact – Supports fail-safe monitoring
• 1 Semiconductor Output – Enables real-time safety signal transmission
• 24V DC Operating Voltage – Ideal for industrial automation applications
• LED Status Indicators – Allows quick diagnostics and troubleshooting
• Compact & Space-Saving Design – Optimized for control panels
• DIN Rail Mounting – Ensures easy installation and reliable integration

Technical Specifications

• Model: Pilz PNOZ X3 (779211)
• Operating Voltage: 24V DC
• Safety Contacts: 3 NO
• Monitoring Contact: 1 NC
• Semiconductor Output: 1 SO
• Connection Type: Screw terminals
• Mounting Type: DIN Rail
• Protection Rating: IP40 (housing), IP20 (terminals)
• Operating Temperature: -25°C to 55°C (-13°F to 131°F)

Applications

• Emergency Stop Monitoring – Ensures fail-safe shutdown of machinery
• Safety Gate & Door Monitoring – Prevents unauthorized access to hazardous areas
• Two-Hand Control Systems – Protects operators from machine hazards
• Light Curtain & Sensor Integration – Enhances automated safety systems
• Presses & Robotics Safety Control – Provides safe motion control and shutdown

Why Choose the Pilz 779211 PNOZ X3?

• Reliable & High-Performance Safety Relay
• Compact & Durable for Industrial Applications
• Ensures Fail-Safe Switching & Machine Safety Compliance
• Easy Installation & Seamless Integration
