Pilz 773732 | PNOZ mc3p Profibus DP Communication Module

Pilz 773732 | PNOZ mc3p Profibus DP Communication Module

Overview

The Pilz 773732 (PNOZ mc3p) is a communication module designed to integrate PNOZmulti safety controllers with PROFIBUS-DP fieldbus systems. This module enables efficient data exchange between safety devices and control systems, enhancing the flexibility and scalability of industrial automation applications.

Key Features

• PROFIBUS-DP Slave Interface – Facilitates seamless communication with PROFIBUS-DP networks.
• Configurable Virtual I/O – Supports 24 to 128 virtual inputs and outputs, customizable via the PNOZmulti Configurator.
• Standard Fieldbus Connection – Equipped with a 9-pin D-Sub female connector for straightforward integration.
• Compact Design – 22.5 mm width optimizes space in control cabinets.
• LED Status Indicators – Provides real-time diagnostics for efficient troubleshooting.
• DIN Rail Mounting – Ensures easy and secure installation.

Technical Specifications

• Model: 773732
• Series: PNOZ mc3p
• Fieldbus Interface: PROFIBUS-DP (Slave)
• Fieldbus Connection: 9-pin D-Sub female connector
• Station Address Range: 0 – 99
• Transmission Rates: 9.6 kBit/s – 1 Mbit/s
• Virtual I/O: 24/128 Bit inputs and outputs
• Dimensions (W x H x D): 22.5 mm x 94.0 mm x 119.0 mm
• Weight: Net 119 g; Gross 138 g
• Operating Temperature: 0°C to +60°C
• Approvals: CE, cULus Listed, EAC, TÜV, KOSHA, CCC, KCC

Applications

• Industrial Automation – Enhances communication between safety controllers and PROFIBUS-DP networks.
• Safety System Integration – Allows seamless integration of PNOZmulti controllers into existing fieldbus architectures.
• Process Monitoring – Facilitates real-time data exchange for monitoring and controlling industrial processes.

Why Choose the Pilz 773732 PNOZ mc3p?

• Reliable Communication – Ensures consistent and secure data exchange within PROFIBUS-DP networks.
• Flexible Configuration – Customizable virtual I/O accommodates diverse application requirements.
• Compact and Durable – Designed for efficient use of control cabinet space and long-term operation.
• Global Certifications – Complies with international standards, ensuring suitability for worldwide applications.

Order Now

Enhance your safety system's connectivity with the Pilz 773732 PNOZ mc3p Profibus DP communication module. Fast shipping and worldwide delivery available.
