Pepperl+Fuchs UC500-D1-3K-V7

Pepperl+Fuchs UC500-D1-3K-V7 | Cylindrical Ultrasonic Sensor for 500 mm Distance Detection

Overview

The UC500-D1-3K-V7 from Pepperl+Fuchs is a robust ultrasonic proximity sensor with a 500 mm sensing range, optimized for non-contact detection of objects regardless of shape, color, or surface texture. Featuring a PNP normally open output, 3-wire DC connection, and IP67-rated cylindrical housing, this model is well-suited for industrial automation and level monitoring tasks.

Key Features

• 500 mm Sensing Range – Accurate mid-range detection

• Ultrasonic Detection – Works on transparent or irregular surfaces

• PNP Output (Normally Open) – Direct interface with PLC inputs

• Prewired Cable (2 m) – Secure and permanent connection

• Cylindrical Housing – Durable, standard format for easy installation

• IP67 Protection – Fully sealed against dust and water ingress

Technical Specifications

• Model: UC500-D1-3K-V7

• Part Number: 212371

• Sensor Type: Ultrasonic proximity sensor

• Measuring Range: 50 mm to 500 mm

• Output Type: PNP, Normally Open (NO)

• Connection Type: 2 m cable, 3-wire DC

• Voltage Supply: 10–30 V DC

• Response Time: ≤ 100 ms

• Switching Frequency: ≤ 5 Hz

• Housing Material: Plastic

• Housing Type: Cylindrical M18

• Protection Rating: IP67

• Operating Temperature: -25°C to +70°C

Applications

• Automated Material Handling

• Presence Detection on Conveyors

• Short-Range Level Sensing

• Packaging and Sorting Equipment

• Transparent or Glossy Object Detection

Why Choose UC500-D1-3K-V7?

• Versatile detection performance in tough environments

• Reliable sensing regardless of object material

• Compact and rugged for industrial integration
