Pepperl+Fuchs PMI120-F90-IU-V1 | 120 mm | Analog Output | IP67

Pepperl+Fuchs PMI120-F90-IU-V1 | Inductive Positioning System, 120 mm, Analog Output, IP67

Overview:

The Pepperl+Fuchs PMI120-F90-IU-V1 (Part No. 191136) is a high-precision inductive positioning system engineered for non-contact linear position detection over a 120 mm measuring range. This unit is ideal for continuous analog feedback in automation and motion control systems, offering robust performance even in harsh industrial settings.

Key Features:

• Measuring Range: 0–120 mm

• Output Type: Analog IU (Current 4–20 mA and Voltage 0–10 V)

• Resolution: 0.1 mm

• Repeat Accuracy: ±0.15 mm

• Power Supply: 15–30 VDC

• Protection Rating: IP67 – Dust-tight and water-resistant

• Housing Type: F90 compact flat housing

• Connection Type: M12 5-pin connector

• Temperature Range: -25°C to +70°C

• LED Indicators: Status and alignment indicators

Technical Specifications:

• Model Number: PMI120-F90-IU-V1

• Part Number: 191136

• Technology: Inductive linear measurement

• Operating Voltage: 15–30 VDC

• Output Signal: 0–10 V and 4–20 mA (switchable)

• Linearity Deviation: ≤ 1% of measuring range

• Material: Housing – plastic; Sensing face – LCP

• Mounting: Surface mount with alignment aid

• Cable/Connector: M12 x 1 male, 5-pin

• Weight: Approx. 250 g

Applications:

• Packaging Machines: Continuous position tracking of actuators

• Machine Tools: Precise part alignment and travel detection

• Robotics: Linear motion feedback for end effectors

• Automation Systems: Position feedback in moving assemblies

• Material Handling: Detecting position of moving loads

Why Choose the PMI120-F90-IU-V1?

✅ Wide 120 mm measuring range for larger applications
✅ Dual analog output (current + voltage) adds flexibility
✅ Compact F90 housing for space-saving installation
✅ Rugged design with IP67 protection ensures long life
✅ Ideal for continuous monitoring of linear motion

Order Now:

Ready for global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
