Pepperl+Fuchs NBN40-L2-E2-V1 (187484) | Inductive Proximity Sensor – 40 mm Sensing Distance

Overview

The NBN40-L2-E2-V1 is a non-contact inductive proximity sensor from Pepperl+Fuchs, designed to detect metallic objects within a 40 mm range. With a rectangular housing, adjustable and rotatable sensor head, and IP68/IP69K protection, this model is ideal for harsh industrial applications such as material handling, conveyors, and packaging systems.

Its M12 connector, PNP output, and normally open switching function ensure fast installation and integration with most control systems.

Key Features

• Sensing Range: 40 mm (non-flush mounting)

• Output Type: PNP, Normally Open (NO)

• Operating Voltage: 10–30 V DC

• Switching Frequency: Up to 180 Hz

• Mounting: Non-flush with included quick-mount bracket

• LED Indicators: 360° visible status indication (4 LEDs)

• Sensor Head: Rotatable for flexible orientation

• Connection Type: M12 × 1, 4-pin connector

• Housing Material: PA (Polyamide)

• Protection Class: IP68 / IP69K (ideal for washdown areas)

• Operating Temperature: -25 °C to +85 °C

Technical Specifications

• Model Number: NBN40-L2-E2-V1

• Manufacturer Part Number (MPN): 187484

• Output Load: Max. 250 mA

• Short-circuit Protection: Yes

• Reverse Polarity Protection: Yes

• EMC Compliance: IEC 60947-5-2

• Installation Type: Surface-mount with bracket (included)

• Hysteresis: Typically 5% of sensing distance

• Weight: Approx. 180 g

Applications

• Material Handling Systems – Position detection on conveyors

• Automated Assembly Lines – Part presence and alignment

• Food & Beverage Equipment – Washdown-ready detection

• Packaging Machines – Reliable metallic object sensing

Why Choose the NBN40-L2-E2-V1?

• Extended 40 mm sensing distance

• Flexible, rotatable sensor head

• Rugged IP69K design for demanding environments

• Quick, tool-less installation
