Overview

The KFD2-SOT3-Ex2 (262108) is a dual-channel isolated switch amplifier from Pepperl+Fuchs, designed to transmit digital signals from hazardous area field devices to the safe area. Compatible with NAMUR sensors or dry contacts, this unit provides passive transistor outputs and supports SIL 2 functional safety.

Its compact design and fast response time make it ideal for process automation, chemical plants, and safety-critical systems requiring intrinsic safety compliance.

Key Features

• Input Type: NAMUR sensor or mechanical contact (2 channels)

• Output Type: Passive transistor (open collector)

• SIL Compliance: SIL 2 (SC3) per IEC/EN 61508

• Line Fault Detection: Short-circuit/open circuit detection (LFD)

• Mode Configuration: DIP-switch programmable (light/dark-on, LFD enable/disable)

• Power Supply: 24 V DC via terminals or Power Rail

• Mounting: DIN rail

Technical Specifications

• Model: KFD2-SOT3-Ex2

• Manufacturer Part Number: 262108

• Supply Voltage: 19–30 V DC

• Input Characteristics:

  • U₀ ≈ 10 V DC

  • I₀ ≈ 8 mA

  • Switching Threshold: 1.2 mA (ON), 2.1 mA (OFF)

• Output Rating:

  • Max 30 V DC

  • Max 100 mA (per output)

  • Short-circuit protected

• Response Time: < 200 µs

• Protection Class: IP20

• Ambient Temp Range: -20 °C to +60 °C

• Dimensions: 20 mm (W) × 119 mm (H) × 115 mm (D)

• Mounting Method: DIN rail (per EN 60715)

Applications

• Signal transfer from hazardous areas to PLC/DCS systems

• Oil & gas and petrochemical industries

• Explosion-proof instrumentation panels

• Safety-critical automation and control circuits

Why Choose the KFD2-SOT3-Ex2?

• Intrinsic safety certified with fast signal processing

• Compact, reliable, and DIN rail mountable

• Dual-channel efficiency in a single housing

• Easy configuration via DIP switches
