Pepperl+Fuchs KFD2-SH-Ex1.T.OP | SIL 3 Isolated Switch Amplifier,

Pepperl+Fuchs KFD2-SH-Ex1.T.OP | Single-Channel Switch Amplifier – SIL 3, Relay & Voltage Output

Overview

The KFD2-SH-Ex1.T.OP (70100833) is a single-channel isolated switch amplifier from Pepperl+Fuchs, designed for intrinsic safety applications. It transfers signals from NAMUR sensors or mechanical contacts in hazardous areas to control systems in the safe area. The module supports SIL 3 functional safety and features line fault detection, a relay output, an active voltage output, and a fault indication output.

This unit is suitable for high-reliability process control and emergency shutdown (ESD) applications.

Key Features

• Input Type: NAMUR sensor or mechanical contact

• Output Options:

  • Relay contact (48 V AC/DC, 250 mA max)

  • Active voltage output (open collector type)

  • Fault output for diagnostics

• Safety Rating: SIL 3 (per IEC 61508/61511)

• Line Fault Detection (LFD): Monitors for open/short circuits

• Supply Voltage: 20–30 V DC (typically 24 V)

• Mounting Type: DIN rail

• Power Rail Compatible: Yes

• Configuration: DIP switch programmable

Technical Specifications

• Model: KFD2-SH-Ex1.T.OP

• Part Number: 70100833

• Operating Voltage: 24 V DC nominal

• Input Voltage (Open Circuit): Approx. 8.4 V

• Input Current (Short Circuit): Approx. 11.7 mA

• Response Time: < 1 ms

• Relay Contact Rating:

  • Max. 48 V AC/DC, 250 mA

  • Resistive load

• Ambient Temperature: -20 °C to +60 °C

• Enclosure Rating: IP20 (panel mount recommended)

• Dimensions: 20 mm (W) × 119 mm (H) × 115 mm (D)

• Weight: Approx. 150 g

Applications

• Safety instrumented systems (SIS)

• Oil & gas and petrochemical ESD interfaces

• Process automation in hazardous environments

• Intrinsically safe signal transfer from field devices

Why Choose the KFD2-SH-Ex1.T.OP?

• Certified for SIL 3 use in safety-critical loops

• Offers both relay and voltage outputs

• Built-in fault diagnostics ensure operational reliability

• Compatible with Pepperl+Fuchs Power Rail system

Order Now

Fast shipping and worldwide delivery available.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
