Pepperl+Fuchs 3RG6013-3AF00 | M30 | 15 mm | PNP NO | IP69K | DC 3-Wire

Pepperl+Fuchs 3RG6013-3AF00 | Inductive Sensor, M30, 15 mm, PNP NO, IP68/IP69K

Overview:

The Pepperl+Fuchs 3RG6013-3AF00 is a heavy-duty inductive proximity sensor in an M30 stainless steel housing, designed for 15 mm non-flush sensing. With PNP normally open output, DC 3-wire connection, and IP68/IP69K protection, this sensor is ideal for food-grade, washdown, and industrial environments where moisture, vibration, and corrosion are concerns.

Key Features:

• Sensing Distance: 15 mm (non-flush mount)

• Output Type: PNP, Normally Open (NO)

• Operating Voltage: 10–30 VDC

• Wiring Configuration: DC 3-wire

• Connection Type: M12 connector, 4-pin

• Housing Material: Full stainless steel body

• Protection Rating: IP68 / IP69K

• Switching Frequency: Up to 250 Hz

• Status Indicator: Integrated LED

• Temperature Range: -25°C to +85°C

Technical Specifications:

• Model Number: 3RG6013-3AF00

• Sensor Type: Inductive proximity sensor

• Installation Type: Non-flush

• Voltage Drop: ≤ 2.5 V

• Max Load Current: 200 mA

• Current Consumption: ≤ 15 mA

• Short-Circuit Protection: Yes

• Reverse Polarity Protection: Yes

• Dimensions: M30 x ~60 mm

• Weight: Approx. 200 g

Applications:

• Food & Beverage: Withstands washdowns and chemical cleaners

• Packaging Automation: Reliable object detection in wet conditions

• Machine Tools: Metal sensing in rugged and oily environments

• Logistics & Conveyors: Long-range detection of bins and metal items

• Outdoor Installations: Corrosion-resistant design for exposed environments

Why Choose the 3RG6013-3AF00?

✅ Long 15 mm detection with non-flush sensing
✅ IP69K rating for extreme washdown and hygiene zones
✅ Stainless steel construction resists wear and corrosion
✅ Reliable PNP NO output with fast switching speed
✅ Perfect for demanding industrial and hygienic applications

Order Now:

Available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
