Pepperl+Fuchs 3RG4022-0AG01 | M30 | 10 mm | PNP NO | DC 3-Wire | IP67

Pepperl+Fuchs 3RG4022-0AG01 | Inductive Sensor, M30, 10 mm, PNP NO, IP67

Overview:

The Pepperl+Fuchs 3RG4022-0AG01 is a robust inductive proximity sensor in a standard M30 cylindrical housing, offering a 10 mm flush sensing distance. With PNP normally open output and IP67 protection, it is ideal for demanding automation applications requiring reliable metal detection in harsh environments.

Key Features:

• Sensing Distance: 10 mm (flush mount)

• Output Type: PNP, Normally Open (NO)

• Wiring Type: 3-wire DC

• Operating Voltage: 10–30 VDC

• Housing Type: M30 x 1.5, nickel-plated brass

• Connection: Pre-wired cable (2 m PVC)

• Protection Class: IP67

• Switching Frequency: Up to 200 Hz

• Temperature Range: -25°C to +70°C

• LED Indicator: Yes, for operation status

Technical Specifications:

• Model Number: 3RG4022-0AG01

• Sensor Type: Inductive proximity

• Installation Type: Flush

• Voltage Drop: ≤ 2.5 V

• Max Load Current: 200 mA

• No-Load Current Consumption: ≤ 10 mA

• Short-Circuit Protection: Yes

• Reverse Polarity Protection: Yes

• Cable Length: 2 meters

• Weight: Approx. 150 g

Applications:

• Machine Tools: Metal object detection in harsh industrial settings

• Material Handling: Position monitoring on conveyor systems

• Packaging Automation: Accurate part detection and control

• Heavy Equipment: Durable sensing in vibration-prone areas

• OEM Systems: Versatile and easily integrated in control panels

Why Choose the 3RG4022-0AG01?

✅ Reliable 10 mm flush detection with consistent performance
✅ Standard M30 housing ensures easy integration
✅ Durable IP67 construction resists dust and water
✅ 3-wire DC PNP output is PLC-compatible
✅ Ideal for both general and heavy-duty automation
