Panasonic GXL-15FU | Compact Inductive Proximity Sensor (Front Sensing, 4 mm)

Overview

The Panasonic GXL-15FU is a micro-size inductive proximity sensor designed for precise front sensing of metal objects in limited-space environments. With a 4 mm rated sensing distance, rugged build, and IP67 protection, it is ideal for integration into automation equipment, robotics, and small machinery.

This model features a DC 2-wire, normally open output, and comes in a rectangular housing for easy flush mounting where cylindrical sensors may not fit.

Key Features

• Front Sensing Type – Stable detection of metal targets from the front face

• Rated Sensing Distance: 4 mm (max. 5 mm)

• Output Type: DC 2-wire, Normally Open (NO)

• Compact Body: Only 15 mm wide, ideal for narrow spaces

• Protection Rating: IP67 – Dust and water resistant

• High Response Frequency: Up to 1,000 Hz

• Power Supply: 12–24 V DC

Technical Specifications

• Model: GXL-15FU

• Sensing Distance: 4 mm (rated), 5 mm (max.)

• Output Type: DC 2-wire, Normally Open (NO)

• Sensing Direction: Front sensing

• Standard Target: Iron, 18 × 18 × 1 mm

• Power Supply: 12–24 V DC ±10%

• Current Consumption: ≤ 1.8 mA

• Response Frequency: 1,000 Hz

• Protection Rating: IP67

• Operating Temperature: –25 to +70 °C

• Housing Material: PBT (Polybutylene terephthalate)

• Cable: 1 m standard cable (other lengths available, e.g., GXL-15FU-C5 = 5 m)

Applications

• Robotics – End-position detection on moving arms

• Conveyors – Presence detection of small metal parts

• Packaging Machines – Compact integration into automated stations

• Assembly Lines – Detection in tight, high-speed environments

Why Choose the Panasonic GXL-15FU?

• Compact size for limited space applications

• Reliable metal detection with fast switching

• Durable IP67 housing for harsh industrial environments

Discontinuation Notice

The GXL series was discontinued in September 2022. Panasonic recommends the GX-F/H series as an alternative with improved features.
