Panasonic AFPX-E30R | PLC Expansion Unit, 16 Digital Inputs / 14

Panasonic AFPX-E30R | I/O Expansion Unit for FP-X Series PLCs

Overview

The Panasonic AFPX-E30R is an expansion I/O unit for the FP-X series programmable logic controllers (PLCs), providing an additional 16 digital inputs and 14 relay outputs. It is designed to extend the control capabilities of an existing FP-X PLC system in applications requiring more discrete I/O points.

This unit features a universal power supply (100–240V AC), making it compatible with a wide range of industrial power environments. Its DIN-rail mountable design, compact housing, and screw terminal wiring simplify installation in control panels.

Key Features

• 16 Digital Inputs (24 V DC) – Sink/source compatible

• 14 Relay Outputs – Rated for 2 A at 250 V AC or 30 V DC

• Input Indicators – Status LEDs for all I/O channels

• Power Supply: 100–240 V AC

• Mounting: DIN rail or panel mount

• Connection: Screw terminal block

• Robust Design: Ideal for industrial environments

Technical Specifications

• Model: AFPX-E30R

• Input Channels: 16 (24 VDC logic level)

• Output Channels: 14 relay outputs (NO contacts)

• Output Rating: Max. 2 A per output (resistive load)

• Power Supply: 100–240 V AC, 50/60 Hz

• Response Time: ≤10 ms (typical)

• Dimensions: Approx. 90 x 90 x 60 mm

• Mounting: DIN rail or screw-mounted

• Operating Temp: 0 to +55 °C

• Weight: Approx. 350 g

• Series Compatibility: Panasonic FP-X CPUs (and FP-XH)

Applications

• Industrial Machines – Control of actuators, sensors, lights, and relays

• Material Handling – Extended I/O for conveyors and sorting systems

• Process Automation – Multi-point input/output control

• Building Automation – Lighting, HVAC, and equipment switching

Why Choose the AFPX-E30R?

• Expand your FP-X PLC system with reliable relay output control

• Universal AC power input for flexible installation

• High-density I/O in a compact footprint

• Proven Panasonic reliability and ease of integration
