Omron NX102-9020 | NX1 Machine Automation Controller

Omron NX102-9020 | NX1 Series Compact Machine Controller – Integrated Motion, EtherNet/IP, OPC UA

Overview

The Omron NX102-9020 is a compact, high-performance machine automation controller from the NX1 series, combining motion control, logic, safety, I/O, and connectivity in one platform. It features 4 built-in EtherNet/IP ports, supports OPC UA for secure industrial data communication, and includes SQL database connectivity for real-time data logging and traceability.

Designed for smart manufacturing, the NX102-9020 provides synchronized control of up to 12 motion axes and seamless integration with Omron’s Sysmac Studio environment.

Key Features

• 4 Built-in EtherNet/IP Ports – Separate networks for safety, control, and IT

• OPC UA Server Functionality – Secure data exchange with MES/SCADA systems

• SQL Client Function – Direct database access for traceability and analytics

• Integrated Motion Control – Up to 12 axes (synchronized)

• Fast Program Execution – Ideal for high-speed machine control

• 40MB Memory – 5MB program, 15MB variable, 20MB file

• Built-in Web Server – For remote monitoring and diagnostics

Technical Specifications

• Catalog Number: NX102-9020

• Series: NX1 Machine Automation Controller

• Program Capacity: 5MB

• Variable Memory: 15MB

• File Memory: 20MB

• Motion Control: Up to 12 axes

• Ethernet Ports: 4 (including EtherNet/IP, OPC UA, Safety)

• Supported Protocols: OPC UA, EtherNet/IP, FTP, HTTP, SNTP

• Programming Software: Omron Sysmac Studio

• Power Supply: 24V DC

• Operating Temperature: 0°C to +55°C

• Mounting: DIN rail

• Weight: Approx. 450 g

Applications

• Smart Machine Control – Synchronize motion, logic, and safety

• Industrial IoT & Data Logging – Via SQL and OPC UA integration

• OEM Equipment – Compact, all-in-one automation platform

• Food, Pharma, Packaging – Fast, connected, and traceable automation

Why Choose the NX102-9020?

• Multi-network connectivity and motion control in one device

• Built-in OPC UA and SQL support for Industry 4.0 applications

• Compact form factor with high performance for smart machines

Order Now

In stock and ready for global shipping. Unlock integrated control, traceability, and connectivity with the NX102-9020 controller.
