Omron CJ1W-CTL41E | High-Speed Pulse Output Unit, 4-Channel,

Omron CJ1W-CTL41E | High-Speed Pulse Output Unit, 4-Channel, CJ-Series

Overview

The Omron CJ1W-CTL41E is a high-speed pulse output unit designed for use with Omron CJ-series programmable logic controllers (PLCs). With 4 independent pulse output channels, this module enables precise positioning control, making it ideal for servo and stepper motor applications in automation, robotics, and CNC systems.

The CJ1W-CTL41E supports various pulse control modes, including pulse and direction (P/D), up/down pulse, and quadrature output, ensuring flexible and accurate motion control.

Key Features

• 4-Channel High-Speed Pulse Output – Supports precise motion and positioning control
• Compatible with CJ-Series PLCs – Integrates seamlessly into Omron automation systems
• Multiple Control Modes:
  • Pulse and Direction (P/D)
  • Up/Down Pulse
  • Quadrature Output
• Supports Stepper & Servo Motor Control – Ideal for precision applications
• High-Speed Pulse Generation – Ensures accurate synchronization and response
• Compact & DIN Rail Mountable – Allows easy installation in control panels

Technical Specifications

• Model: CJ1W-CTL41E
• Number of Channels: 4 Pulse Outputs
• Pulse Output Modes: Pulse & Direction, Up/Down, Quadrature
• Compatible PLC Series: Omron CJ-Series
• Mounting Type: DIN Rail / Panel Mount
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Certifications: CE, UL, RoHS

Applications

• Servo & Stepper Motor Control – Provides precise motion control
• Conveyor & Material Handling Systems – Ensures smooth automation
• CNC & Robotics – Supports high-speed positioning and motion synchronization
• Automated Assembly Lines – Enhances accuracy and efficiency

Why Choose the Omron CJ1W-CTL41E?

• Reliable High-Speed Pulse Output – Ensures precise motion synchronization
• Flexible Control Modes – Compatible with various motor control applications
• Seamless Integration with Omron CJ-Series PLCs – Ensures efficient system operation
• Compact & Space-Saving Design – Ideal for control panel installations

Order Now

Fast shipping and worldwide delivery available.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
