Mitsubishi CM900DU-24NF

Mitsubishi CM900DU-24NF

Overview

The Mitsubishi CM900DU-24NF is a high-power IGBT module with dual transistor configuration, designed for heavy-duty industrial applications. With a current rating of 900 A and voltage capacity of 1200 V, this module utilizes trench-gate technology and built-in fast recovery diodes to deliver efficient switching, low power loss, and superior thermal performance.

Key Features

• Dual IGBT half-bridge module

• Collector current: 900 A

• Collector-emitter voltage: 1200 V

• Trench-gate IGBT structure

• Integrated fast-recovery diodes

• Insulated baseplate for optimized thermal transfer

• Rugged chassis mount package

• Designed for high-current industrial use

Technical Specifications

• Part Number: CM900DU-24NF

• Configuration: Dual IGBT

• Collector Current: 900 A (continuous)

• Collector-Emitter Voltage: 1200 V

• VCE(sat): ~2.0–2.2 V @ rated current

• Gate-Emitter Voltage: ±20 V

• Switching Speed: Fast

• Thermal Resistance (Junction-Case): ~0.025 °C/W

• Mounting Type: Chassis mount (insulated)

• Operating Temperature: –40 °C to +150 °C

• Package Type: High-power IGBT module

• Weight: Approx. 800–900 g

Applications

• High-capacity inverters and drives

• Industrial automation and robotics

• Traction and railway systems

• Wind and solar power converters

• Large-scale UPS and energy systems

Why Choose the CM900DU-24NF

• Massive 900 A current rating with 1200 V blocking voltage

• Excellent efficiency and thermal performance

• Mitsubishi quality and long-term reliability

• Suitable for the most demanding power applications

• Simplified mounting with insulated baseplate

Order Now

The Mitsubishi CM900DU-24NF IGBT module is available and ships worldwide.

This product is part of our Mitsubishi IGBT Modules collection, designed for high-efficiency power conversion and reliable performance in industrial automation. Browse the complete range of Mitsubishi IGBT Modules.

Explore the Power Electronics Components main category to discover diodes, thyristors, GTOs, MOSFETs, and other semiconductor solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
