Mitsubishi FX5UC-32MT/DS-TS

Mitsubishi FX5UC-32MT/DS-TS

Overview

The Mitsubishi FX5UC-32MT/DS-TS is a compact PLC CPU module from the FX5UC series, offering 32 total digital I/O points (16 inputs and 16 transistor outputs) at 24V DC. UL listed and featuring a touchscreen option port, this CPU delivers high‑speed processing, onboard Ethernet/USB, and is optimized for integration with the touchscreen operator interface.

Key Features

• Series: MELSEC iQ‑F (FX5UC)

• Power Supply: 24 V DC

• Total I/O Points: 32 (16 inputs + 16 outputs)

• Output Type: Transistor (sink type)

• Safety Listing: UL certified

• Touchscreen Port: Dedicated interface for touchscreen HMIs

• Built‑In Functions: Ethernet, USB, high‑speed counters, pulse outputs

• Memory Capacity: 64k program steps, 128k data words

• Mounting: DIN rail or panel mount

Technical Specifications

• Model Number: FX5UC‑32MT/DS‑TS

• Digital Inputs: 16 (sink/source, 24 V DC)

• Digital Outputs: 16 (sink transistor, 0.5 A per point)

• High‑Speed I/O: 8 × 200 kHz counters, 4 × 200 kHz pulse outputs

• Communication Ports: Ethernet 10/100 Mbps, USB Device

• Program Memory: 64 k steps

• Ambient Operating Temp: 0°C to 55°C

• Protection Rating: IP10 (installed)

• Certifications: CE, UL, cUL, RoHS

• Dimensions: Approx. 90 × 150 × 83 mm

• Weight: ≈ 0.6 kg

Applications

• Small to mid-size machine automation with touchscreen access

• Packaging and labeling systems

• Conveyor and material handling controls

• Pick-and-place systems with GUI

• Compact industrial control panels

Why Choose the FX5UC-32MT/DS-TS

• UL-Certified Design: Ideal for North American installations

• Touchscreen Ready: Prewired interface for operator panels

• Integrated Communication: Built-in Ethernet and USB support

• High-Speed Processing: Fast I/O and pulse handling for dynamic tasks

• Modular Expandability: Supports FX5U expansion modules

Order Now

The Mitsubishi FX5UC-32MT/DS-TS PLC is available and ships worldwide.

Return to the Mitsubishi FX5 Series PLC collection for more options in this family.

Explore our full range of Mitsubishi MELSEC Programmable Controllers (PLC) to discover scalable automation solutions, from legacy systems to next-generation PLCs designed for high performance, connectivity, and flexibility.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
