Mitsubishi FX5-4AD-ADP

Mitsubishi FX5-4AD-ADP | 4-Channel Analog Input Adapter for FX5U/FX5UC PLCs

Overview

The Mitsubishi FX5-4AD-ADP is a 4-channel analog input adapter designed for the MELSEC iQ-F FX5U and FX5UC PLC series. It supports voltage and current input signals, allowing for accurate analog signal processing in a wide range of automation applications. Its slim, compact profile makes it ideal for DIN rail mounting in space-constrained control panels.

Key Features

• Number of Channels: 4 analog inputs

• Input Signal Types: 0–10V, 1–5V, 0–5V, 4–20mA, 0–20mA

• High Resolution: 12-bit digital resolution

• Connection Type: ADP (adapter-type extension module)

• Installation: DIN rail mountable

• Real-Time Monitoring: Supports continuous input signal tracking

• Compact Design: Optimized for tight control panels

Technical Specifications

• Model: FX5-4AD-ADP

• Series Compatibility: FX5U, FX5UC

• Signal Types: Voltage (±10V), Current (±20mA)

• Input Impedance: Voltage: 200kΩ or more, Current: 250Ω

• Conversion Speed: 2 ms per channel

• Operating Temperature: 0°C to 55°C

• Weight: Approx. 0.2 kg (0.44 lbs)

• Certifications: CE, UL

Applications

• Temperature and pressure monitoring

• Analog sensor data acquisition

• Process control systems

• Machine diagnostics

• Environmental data logging

Why Choose the FX5-4AD-ADP?

• Versatile Analog Input Support: Handles both voltage and current signals

• Seamless FX5 Integration: Direct connection to FX5U/FX5UC PLCs

• Space-Saving Footprint: Perfect for compact automation setups

• Reliable Performance: Mitsubishi quality and industrial durability

Order Now

The Mitsubishi FX5-4AD-ADP analog input module is in stock.

Return to the Mitsubishi FX5 Series PLC collection for more options in this family.

Explore our full range of Mitsubishi MELSEC Programmable Controllers (PLC) to discover scalable automation solutions, from legacy systems to next-generation PLCs designed for high performance, connectivity, and flexibility.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
