Mitsubishi FR-E720-0.4K

Mitsubishi FR-E720-0.4K

Overview

The Mitsubishi FR-E720-0.4K is a compact frequency inverter from the FR-E700 series, delivering 0.4 kW output power and operating on a single-phase 200–240 V AC supply. Featuring advanced vector control, built-in PLC functions, and a user-friendly interface, it is ideal for precise motor drive applications in compact industrial machinery.

Key Features

• Power Output: 0.4 kW (0.5 HP)

• Input Voltage: Single-phase 200–240 V AC

• Control Modes: V/f and sensorless vector control

• Compact IP20 housing for panel mounting

• LCD keypad display with parameter editing

• Built-in PID controller for process control

• Dynamic torque boost and auto-tuning

• Multi-function relay and analog I/O built-in (optional expansion)

Technical Specifications

• Model Number: FR-E720-0.4K

• Output Power: 0.4 kW

• Input Voltage: 200–240 V AC ±10%, 50/60 Hz

• Output Frequency: 0–400 Hz

• Overload Rating: 150% for 60 s

• Environmental Rating: IP20 enclosure

• Control Interface: Built-in keypad, analog/digital I/O

• Cooling: Built-in fan

• Mounting: Panel or DIN-rail with option bracket

• Ambient Temp Range: –10 °C to +50 °C

• Certifications: CE, UL, cUL, RoHS

Applications

• Small conveyor and packaging machines

• Laboratory equipment and test benches

• HVAC fan and pump control

• Light-duty machine tools

• OEM machinery requiring precise and compact motor control

Why Choose the FR-E720-0.4K

• Compact design perfect for tight panel space

• Offers advanced vector performance without encoder

• User-friendly configuration with LCD keypad

• Integrated PLC features reduce external control requirements

• Proven reliability from Mitsubishi's FR series drives

Order Now

The Mitsubishi FR-E720-0.4K frequency inverter is available and ships worldwide.

Discover more options in the Mitsubishi FR Series Frequency Inverters (FREQROL category, designed for precision motor control, energy efficiency, and industrial automation.

For additional solutions, explore the full range of Mitsubishi products.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
