Mitsubishi AJ65SBTB1-32DT

Mitsubishi AJ65SBTB1-32DT

Overview

The Mitsubishi AJ65SBTB1-32DT is a 32-point transistor output module designed for remote I/O applications using the CC-Link network. It features sink-type outputs and enables high-speed communication and reliable output control in distributed automation environments.

Key Features

• 32 digital outputs (sink type)

• Output Voltage: 24 V DC

• Output Current: 0.1 A per point (max)

• Supports CC-Link Ver. 1.10/2.00

• Fast, real-time I/O refresh via CC-Link

• Integrated terminal block for simplified wiring

• LED status indicators for diagnostics

• Compact DIN-rail or panel mount design

Technical Specifications

• Model Number: AJ65SBTB1-32DT

• Output Points: 32 (transistor, sink type)

• Output Voltage: 24 V DC

• Output Current: 0.1 A/point, 2 A/common

• Response Time: ≤1 ms

• Network: CC-Link (remote I/O station)

• Communication Speed: 156 kbps – 10 Mbps

• Power Supply: 24 V DC

• Mounting: DIN rail or direct panel

• Operating Temp: 0 °C to +55 °C

• Certifications: CE, UL, cUL, RoHS

Applications

• Distributed digital output control

• Packaging and assembly machinery

• Material handling systems

• Remote expansion for MELSEC PLCs via CC-Link

• OEM equipment requiring compact I/O modules

Why Choose the AJ65SBTB1-32DT

• High-density output in a compact unit

• Seamless CC-Link communication integration

• Mitsubishi reliability for demanding applications

• Easy to install and maintain

• Optimized for space-efficient control cabinets

Order Now

The Mitsubishi AJ65SBTB1-32DT output module is available and ships worldwide.
