Leuze SLSER 25B/66‑S12

Leuze SLSER 25B/66‑S12 | Safety Light Beam Receiver | 25 m Range | Type 4 | M12 Connector

Overview

The Leuze SLSER 25B/66‑S12 is a high-performance Type 4 safety light beam receiver for use in single-beam safety systems. Designed to monitor hazardous points and access areas, it detects beam interruptions over distances up to 25 m. Featuring a compact, robust IP67-rated housing and M12 connector, it ensures compliance with EN/IEC 61496-1/-2 standards and is ideal for critical machine safety applications.

Key Features

• Operating range: Up to 25 m (with matching transmitter)

• Safety Category: Type 4 (IEC/EN 61496-1/-2)

• Receiver unit for single-beam safety system

• Output: PNP safety switching signal

• Compact design with integrated optics

• M12, 4-pin connector for quick connection

• Excellent resistance to ambient light

• IP67-rated enclosure for industrial use

• LED indicators for alignment and function

Technical Specifications

• Catalog Number: 50108492

• Function: Safety light beam receiver

• Safety Type: Type 4

• Operating Range: 0.1 m to 25 m

• Output: PNP (safety-related)

• Supply Voltage: 24 V DC (±20%)

• Connection: M12, 4-pin

• Protection Class: IP67

• Housing Material: Reinforced plastic

• Operating Temperature: –10 °C to +55 °C

• Storage Temperature: –25 °C to +70 °C

• Dimensions: Approx. 55 × 18 × 35 mm

• Weight: Approx. 50 g

Applications

• Machine access control with high safety demand

• Robotics cells and hazardous area monitoring

• Presses, packaging, and material handling systems

• Perimeter guarding in safety-critical installations

• Compliance with SIL 3 / PL e requirements (with proper setup)

Why Choose SLSER 25B/66‑S12

• Certified Type 4 safety receiver for high-risk environments

• Reliable operation with long-range detection up to 25 m

• Compact and rugged build with IP67 protection

• Fast integration using M12 plug-and-play connection

• Ideal for applications demanding the highest safety integrity

Order Now

The Leuze SLSER 25B/66‑S12 safety light beam receiver (Part no. 50108492) is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
