Leuze PRK46C.1/4P-M12

Leuze PRK46C.1/4P-M12 | Retro-Reflective Sensor | 18 m Range | Red Light | M12 Connector | IP67/IP69K

Overview

The Leuze PRK46C.1/4P-M12 is a retro-reflective photoelectric sensor engineered for long-range detection up to 18 meters. With its visible red light beam, PNP light switching output, and polarization filter, it ensures reliable object detection even in reflective environments. It features a robust M12 4-pin connector and is housed in a rugged plastic enclosure rated IP67/IP69K, making it suitable for harsh industrial and washdown applications.

Key Features

• Sensing Range: Up to 18 m with reflector

• Light Source: Red LED, visible

• Output Type: PNP, light switching

• Connection: M12 male connector, 4-pin

• Switching Frequency: Up to 250 Hz

• Enclosure: IP67 / IP69K (high-pressure washdown rated)

• Housing Material: Plastic with reinforced front optics

• Mounting: Universal brackets or through-hole

• Power Supply: 10–30 V DC

Technical Specifications

• Model Number: PRK46C.1/4P-M12

• Sensor Type: Retro-reflective with polarization filter

• Response Time: ≤ 2 ms

• Ambient Operating Temperature: -40°C to +60°C

• Repeat Accuracy: ≤ 5 mm

• Protection Circuits: Overload, short-circuit, reverse polarity

• Status Indicators: Dual LEDs for power and switching state

• Certifications: CE, cULus, Ecolab-tested

Applications

• Long-range object detection on conveyors

• Harsh industrial environments with water or dust exposure

• Packaging and material handling systems

• Warehouse automation

• Food and beverage industry (washdown-rated)

Why Choose the PRK46C.1/4P-M12

• Extended Range: Reliable detection up to 18 meters

• Extreme Durability: IP69K protection for washdown conditions

• Easy Installation: M12 connector with standard mounting options

• Stable Detection: Built-in polarization filter for reflective surfaces

• Trusted Quality: From Leuze, a leader in sensor innovation

Order Now

The Leuze PRK46C.1/4P-M12 retro-reflective sensor is in stock and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
