Leuze ODSL 8/C66‑200‑S12

Leuze ODSL 8/C66‑200‑S12 | Optical Distance Sensor | 20–200 mm | Background Suppression

Overview

The Leuze ODSL 8/C66‑200‑S12 is a compact optical distance sensor equipped with precise background suppression and a detection range of 20 to 200 mm. Utilizing Class 2 laser technology, it provides reliable object detection in tight spaces. The sensor is ideal for applications requiring high positioning accuracy and dependable measurement even with varying backgrounds.

Key Features

• Measurement range: 20 mm to 200 mm

• Reliable background suppression for accurate detection

• Laser Class 2 for precise targeting

• M12 4-pin connector for fast installation

• High switching frequency for rapid detection

• Small, rectangular housing for space-constrained setups

• Ideal for detecting small parts or near-field applications

Technical Specifications

• Catalog Number: 50108362

• Sensing Range: 20 mm to 200 mm

• Sensing Method: Triangulation with background suppression

• Light Source: Red laser, Class 2

• Output: Digital switching output (PNP or NPN, depending on model)

• Supply Voltage: 10–30 V DC

• Connector: M12, 4-pin

• Housing Material: Plastic

• Protection Class: IP67

• Operating Temperature: –10 °C to +50 °C

• Mounting Type: DIN or panel mount

• Dimensions: Approx. 32 × 12 × 20 mm

• Weight: Approx. 10 g

Applications

• Precision object detection on conveyors

• Detection of small parts and components

• Robotics and pick-and-place systems

• Machine guarding and position control

• Presence detection in packaging machinery

Why Choose ODSL 8/C66‑200‑S12

• Accurate detection with background suppression

• Compact design fits in limited space

• Easy electrical integration with M12 connector

• Reliable performance on challenging surfaces

• Designed for fast-paced industrial automation environments

Order Now

The Leuze ODSL 8/C66‑200‑S12 optical distance sensor (Part no. 50108362) is available and ships worldwide.
