Leuze GS 61/6-S8

Leuze GS 61/6-S8 | Fork Photoelectric Sensor | 6 mm Slot Width | Infrared Light | IP67 | S8 Connector

Overview

The Leuze GS 61/6-S8, part number 50110110, is a compact and precise fork photoelectric sensor with a 6 mm slot width designed for high-speed detection of labels, objects, or edges. This sensor operates using infrared light and delivers fast switching performance in tight industrial spaces. Its robust IP67-rated enclosure and S8 plug connector make it ideal for integration into labeling, packaging, and automation systems.

Key Features

• Slot Width: 6 mm

• Light Source: Infrared LED (invisible light)

• Switching Frequency: Up to 10 kHz

• Switching Output: PNP (light or dark switching, depending on model)

• Connector: S8, 3-pin plug

• Protection Class: IP67

• Response Time: ≤ 50 µs

• Power Supply: 10–30 V DC

• Material: Aluminum housing with precise fork gap

• Status Indicators: LED for output and alignment

Technical Specifications

• Model: GS 61/6-S8

• Part Number: 50110110

• Operating Temperature: –20°C to +60°C

• Mounting: Through-holes in sensor body

• Adjustment: Sensitivity via potentiometer (if applicable)

• Certifications: CE, cULus, RoHS

• Output Current Max: 100 mA

• Reproducibility: ≤ 0.03 mm

Applications

• Label detection on labeling machines

• Edge detection in packaging systems

• Counting small parts or materials

• High-speed positioning in assembly lines

• Automation equipment with limited space

Why Choose the GS 61/6-S8

• Precise Detection: Narrow 6 mm slot for small object sensing

• High-Speed Performance: Fast 10 kHz switching for dynamic applications

• Durable Construction: IP67 housing resists dust and moisture

• Simple Integration: Compact design and standard S8 plug

• Proven Leuze Quality: Engineered for industrial automation

Order Now

The Leuze GS 61/6-S8 fork photoelectric sensor (Part No. 50110110) is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
