Lenze SM100

Lenze SM100 | USB Diagnostic Interface Module for Lenze Drives

Overview

The Lenze SM100 is a USB-to-RJ diagnostic interface module that allows direct communication between a PC and Lenze inverters via a dedicated RJ port. Designed for field commissioning, diagnostics, and firmware updates, the SM100 is compatible with popular Lenze engineering tools like EASY Starter and Engineer.

Key Features

• Connection Type: USB (to PC) and RJ (to drive DIAG port)

• Supported Drive Series: Lenze 8200, 8400 StateLine/HighLine, and 9400 HighLine

• Driver Support: Plug-and-play with Lenze EASY Starter software

• Status LEDs: Power and communication indicators

• Compact and Lightweight: Ideal for portable field use

• Plug-and-Play: No external power required

• Rugged Housing: Suitable for industrial environments

Technical Specifications

• Model Number: SM100

• Interfaces:

  • USB 2.0 Type A (host PC)

  • RJ50 10-pin (Lenze DIAG port)

• Cable Compatibility: Works with EWL0071 and EWL0070 cables

• Length: Module body ~70 mm, plus built-in cable

• Operating Temperature: 0°C to 50°C

• Weight: ~0.15 kg

• Certifications: CE compliant

Applications

• Parameter configuration of Lenze drives

• Field service diagnostics

• Commissioning new installations

• Firmware flashing

• Fault code monitoring and resets

Why Choose the SM100?

• Reliable & Fast Communication: Stable diagnostics and parameter access

• Tool-Free Setup: Works instantly with Lenze software

• Supports Multiple Drive Families: Single tool for 8200, 8400, and 9400 series

• Portable: Lightweight and field-ready

• USB Powered: No external power source required

Order Now

The Lenze SM100 diagnostic interface is available and ready to ship.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
