Overview

The Lenze E82ZBC is a braking chopper module designed for use with Lenze 8200 series frequency inverters. It safely dissipates excess braking energy, protecting both the drive and motor in dynamic applications.

Key Features

• Application: Braking energy dissipation

• Compatibility: 8200 series drives

• Operation: Activates when DC bus voltage exceeds threshold

• Connection: Direct connection to inverter DC bus

• Protection: Prevents overvoltage conditions during deceleration

Technical Specifications

• Voltage Range: As per 8200 series specifications

• Switching Type: Electronic (IGBT-based)

• Enclosure Type: IP20 for panel mounting

• Mounting: DIN rail or screw-mounted

• Ambient Temp: -10°C to +45°C

• Weight: Approx. 0.5 kg

• Certifications: CE, UL, RoHS compliant

Applications

• High-inertia load systems

• Elevators and hoists

• Centrifuges

• Fast-stopping conveyors

• Dynamic industrial machinery

Product Description

The Lenze E82ZBC braking chopper module ensures secure operation of 8200 series drives under rapid deceleration or dynamic braking conditions by efficiently redirecting excess energy.

Why Choose Lenze E82ZBC?

• Protects inverters from overvoltage

• Ensures safe braking in demanding conditions

• Easy integration with 8200 drives

• Compact and efficient energy control

Order Now

Upgrade your braking performance with the Lenze E82ZBC, the trusted solution for dynamic load management in automated systems.
