Infineon FS50R12KT4P_B11

Infineon FS50R12KT4P_B11

Overview

The Infineon FS50R12KT4P_B11 is a single IGBT module rated at 50 A and 1200 V, based on Trench & Field‑Stop IGBT4 technology in an EconoDUAL™ 3 chassis‑mount housing. With an integrated NTC thermistor and efficient switching characteristics, it delivers reliable performance in compact inverters, motor drives, and industrial converters.

Key Features

• Collector–Emitter Voltage: 1200 V

• Continuous Collector Current: 50 A

• Trench & Field‑Stop IGBT4 – low conduction and switching losses

• Fast-recovery free-wheeling diode included

• EconoDUAL 3 chassis‑mount package

• Low stray inductance for efficient operation

• Integrated NTC thermistor for temperature monitoring

• Compact and rugged design

Technical Specifications

• Part Number: FS50R12KT4P_B11

• Configuration: Single IGBT module

• Voltage Rating: 1200 V

• Current Rating: 50 A continuous

• Package: EconoDUAL 3

• Isolation Voltage: ≥2500 V

• Mounting Type: Chassis with screw terminals

• Operating Temperature: –40 °C to +150 °C (Tj)

• Switching Frequency: Up to ~20 kHz

• NTC Thermistor: Integrated

Applications

• Compact industrial motor drives

• Three-phase inverters and converters

• UPS and backup power systems

• Renewable energy micro-inverters

• Control and automation equipment

Why Choose the FS50R12KT4P_B11

• High-efficiency switching in a compact chassis form

• Built-in thermal sensor supports system safety

• Reliable and durable for long-term industrial use

• Leverages advanced IGBT4 technology from Infineon

Order Now

The Infineon FS50R12KT4P_B11 IGBT module is available and ships worldwide.
