Infineon DZ800S17K3

Infineon DZ800S17K3 (Semikron-designed)

Overview

The DZ800S17K3 is a rugged IGBT module rated at 800 A and 1700 V, housed in a SEMITRANS 3 chassis-mount package. Specifications match Semikron's design profile. If Infineon is branding this module, it is almost certainly a rebranded OEM version.

Key Features

• Collector–Emitter Voltage: 1700 V

• Continuous Collector Current: 800 A

• Single IGBT configuration with integrated diode

• High-voltage industrial SEMITRANS 3 housing

• Low VCE(sat) and efficient switching

• Chassis mounting with robust electrical isolation

• Optimized for high-power inverter applications

Technical Specifications

• Model: DZ800S17K3

• Collector–Emitter Voltage Rating: 1700 V

• Current Rating: 800 A

• Package: SEMITRANS 3 style (chassis mount)

• Isolation Voltage: ≥2500 V

• Operating Temperature: –40 °C to +150 °C (Tj)

• Switching Frequency: Typically up to 5–10 kHz

• NTC Thermistor: Usually included (verify manufacturer labeling)

Applications

• Traction, locomotive, and rail drives

• High-voltage industrial inverters

• Renewable energy converters

• Grid and power system converters

• Heavy-duty motor and traction control

Why Choose the DZ800S17K3

• Ultra-high voltage and current capacity

• Designed for rugged, high-demand applications

• Most likely OEM design by Semikron, possibly rebranded

• Excellent thermal and electrical performance under load

Order Now

If sourcing under Infineon DZ800S17K3, confirm current provider attribution—chances are it ships as the Semikron-original SEMITRANS module.
