Semikron SKD 146/16-L100

Semikron SKD 146/16-L100

Overview

The Semikron SKD 146/16-L100 is a dual-diode module rated for 1600 V and 2×73 A, engineered for industrial rectification and freewheeling applications. Packaged in the standardized SEMIPACK 1 housing, this version includes L100 design modifications to enhance layout or mechanical compatibility in specific assemblies.

Key Features

• Blocking Voltage: 1600 V

• Forward Current: 2×73 A

• Dual-diode in SEMIPACK 1

• Electrically insulated baseplate

• High overload and surge tolerance

• L100 variant for specific mechanical or layout needs

Technical Specifications

• Module Type: Diode Module (Dual)

• VRRM: 1600 V

• IF(AV): 2×73 A

• Surge Current (IFSM): >1200 A

• Insulation Voltage: ≥2500 V RMS

• Package: SEMIPACK 1 (L100)

• Mounting: Chassis screw mount

• Operating Temp: –40 °C to +150 °C

Applications

• Controlled rectifiers

• Freewheeling circuits

• Motor drives

• UPS and power supplies

• Energy conversion systems

Why Choose the SKD 146/16-L100

• Proven Semikron reliability

• High-current, high-voltage dual-diode design

• Compact, standard footprint

• Enhanced compatibility with L100 mechanical layout

Order Now

The Semikron SKD 146/16-L100 is in stock and ready for global shipping.
