Semikron SKCH 40/12

Semikron SKCH 40/12

Overview

The Semikron SKCH 40/12 is a fast recovery diode module rated at 40 A and 1200 V. Housed in the compact and robust SEMIPACK 1 format, this module is optimized for high-speed switching, low losses, and high surge current capability, making it a reliable choice for demanding power electronics applications.

Key Features

• Reverse Voltage: 1200 V

• Average Forward Current: 40 A

• Fast reverse recovery performance

• Electrically isolated baseplate

• Compact SEMIPACK 1 housing

• High thermal and electrical stability

Technical Specifications

• Module Type: Fast Recovery Diode

• VRRM: 1200 V

• IF(AV): 40 A

• Surge Current: >600 A

• Reverse Recovery Time: ~1.5 µs

• Isolation Voltage: ≥2500 V RMS

• Mounting: Chassis mount

• Operating Temperature Range: –40 °C to +150 °C

Applications

• High-frequency rectification

• Power inverters

• UPS systems

• SMPS and welding machines

• Motor drive circuits

Why Choose the SKCH 40/12

• Excellent switching speed

• Reliable thermal management

• Space-saving SEMIPACK 1 housing

• Backed by Semikron's industrial-grade quality

Order Now

The Semikron SKCH 40/12 fast recovery diode module is available and ships worldwide.

Return to the Semikron IGBT Modules collection for more models, ratings, and configurations.

Explore the Power Electronics Components main category main category to discover diodes, thyristors, GTOs, MOSFETs, and other semiconductor solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
