Semikron SK75GD12T4T

Semikron SK75GD12T4T

Overview

The Semikron SK75GD12T4T is a high-performance IGBT module featuring a dual IGBT configuration rated at 75 A and 1200 V. Designed in a compact SEMITRANS 2 housing, this module is ideal for industrial inverter systems, motor drives, and power conversion applications requiring fast switching, low conduction losses, and reliable thermal management.

Key Features

• Blocking Voltage: 1200 V

• Collector Current: 75 A

• Dual IGBT half-bridge configuration

• SEMITRANS 2 industry-standard housing

• Low saturation voltage (VCE(sat))

• High switching speed and efficiency

• Electrically isolated baseplate

Technical Specifications

• Module Type: Dual IGBT

• VCES: 1200 V

• IC: 75 A

• Configuration: Half-bridge

• Isolation Voltage: ≥2500 V RMS

• Housing: SEMITRANS 2

• Mounting: Chassis mount

• Operating Temperature: –40 °C to +150 °C

Applications

• Industrial motor drives

• AC and DC inverters

• UPS systems

• Renewable energy converters

• General-purpose power electronics

Why Choose the SK75GD12T4T

• Reliable dual IGBT for high-efficiency applications

• Compact and robust SEMITRANS 2 design

• High thermal performance with low switching losses

• Trusted Semikron quality for industrial environments

Order Now

The Semikron SK75GD12T4T IGBT module is available and ships worldwide.

Return to the Semikron IGBT Modules collection for more models, ratings, and configurations.

Explore the Power Electronics Components main category main category to discover diodes, thyristors, GTOs, MOSFETs, and other semiconductor solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
