ifm IGS252 | M30 Flush Inductive Proximity Sensor, 10 mm, PNP

ifm IGS252 | M30 Inductive Proximity Sensor with PNP Output and High Protection Rating

Overview

The ifm IGS252 is a robust M30 inductive proximity sensor with flush mounting, a 10 mm sensing range, and a PNP normally open output. Designed for use in harsh industrial environments, the IGS252 offers exceptional protection (IP68/IP69K), making it ideal for food processing, packaging machinery, and washdown applications.

With an Ecolab-certified stainless steel housing, the IGS252 ensures long-term performance in environments requiring high resistance to water, chemicals, and mechanical stress.

Key Features

• M30 Threaded Housing – Standard size for easy installation

• Flush Mountable – Embeds fully into metal for mechanical protection

• 10 mm Sensing Distance – Reliable detection of metal objects

• PNP Output (Normally Open) – Ideal for most PLC/control systems

• High Protection Rating – IP68/IP69K for use in wet and high-pressure cleaning zones

• Robust Stainless Steel Housing – Ecolab-certified for hygienic environments

• LED Switching Indicator – Clear visual status feedback

• High Shock and Vibration Resistance

Technical Specifications

• Model: IGS252

• Part Number: IGW3008-BPKG/M/US

• Mounting Type: Flush (shielded)

• Thread Size: M30 x 1.5

• Sensing Range: 10 mm

• Output Type: PNP, Normally Open

• Power Supply: 10–36 VDC

• Switching Frequency: 200 Hz

• Electrical Connection: M12 connector, 4-pin

• Housing Material: Stainless steel (1.4404 / 316L)

• Protection Rating: IP68/IP69K

• Temperature Range: –25 to +80 °C

• Certifications: CE, Ecolab, cULus

Applications

• Food & Beverage Industry – Built to withstand aggressive cleaning agents

• Packaging Machines – Reliable detection in high-speed, wet environments

• Automated Washdown Zones – Maintains performance under water jets

• General Industrial Automation – Detects metal targets reliably under tough conditions

Why Choose the ifm IGS252?

• Designed for demanding hygienic and industrial environments

• Flush mounting for added protection and stability

• Long-lasting performance even under extreme cleaning processes

Order Now

Available now for fast global shipping. Matching cables and mounting accessories available separately.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
