GE IC693TCM302

GE Fanuc IC693TCM302 | Series 90-30 Two-Channel Thermocouple Module | Type J, K, E, T, R, S, B, N | 16-Bit Resolution | Isolated Inputs

Overview

The GE Fanuc IC693TCM302 is a 2-channel thermocouple input module for the Series 90-30 PLC system, designed to interface directly with a wide range of thermocouple types for industrial temperature monitoring and control. The module offers 16-bit resolution, cold junction compensation, and channel-to-channel isolation, ensuring precise and reliable temperature data acquisition.

Key Features

• Input Channels: 2 individually isolated

• Supported Thermocouple Types:

  • Type J, K, E, T, R, S, B, N

• Resolution: 16-bit (high accuracy for temperature measurement)

• Cold Junction Compensation: Built-in

• Channel Isolation: 1500V between channels and system logic

• Diagnostics: Status LEDs and fault detection

Technical Specifications

• Model Number: IC693TCM302

• Input Range: Thermocouple dependent (e.g., -200°C to +1800°C)

• Accuracy: ±1.0°C typical

• Update Rate: 500 ms per channel

• Power Requirements: 5V @ 90 mA, 24V @ 50 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

• Configuration Software: Proficy Machine Edition or Logicmaster 90

Applications

• Industrial furnace and oven temperature monitoring

• HVAC and environmental control systems

• OEM machine temperature diagnostics

• Process control involving thermal elements or sensors

Why Choose the IC693TCM302?

• Multi-Type Thermocouple Support: Flexibility in sensor selection

• High Resolution & Accuracy: Ideal for precision temperature control

• Built-In Compensation & Isolation: Ensures stable and reliable readings

• GE Fanuc Proven Design: Industrial-grade performance and longevity

Order Now

The GE Fanuc IC693TCM302 thermocouple input module is in stock and ready for fast international shipping.

Return to GE IC693 PLC Series 90-30 for more options in this series.

 Explore our full range of GE Industrial Automation Products to find PLCs, HMIs, servo drives, control modules, and other automation solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
