GE IC693PWR331

GE Fanuc IC693PWR331 | Series 90-30 Power Supply Module | 120/240VAC or 125VDC Input | 30W Output | With Battery Backup Port

Overview

The GE Fanuc IC693PWR331 is a standard 30W power supply module for the Series 90-30 PLC system. It accepts a wide input range of 120/240VAC or 125VDC and delivers regulated +5VDC and +24VDC outputs to power CPUs, I/O, and communications modules. It also includes a battery backup port to support memory retention for the CPU module.

Key Features

• Input Voltage:

  • 120/240VAC, 50/60Hz

  • 125VDC

• Output Power: 30 watts total

• Outputs Provided:

  • +5VDC @ 5A

  • +24VDC Relay Power @ 0.25A

  • Isolated +24VDC @ 0.125A

• Battery Port: Supports optional memory backup battery

• Mounting Location: Left-most slot in Series 90-30 rack

Technical Specifications

• Model Number: IC693PWR331

• Input Voltage Range: 85–264VAC or 100–150VDC

• Input Frequency: 47–63 Hz

• Power Output: 30W

• Backplane Current Output:

  • +5VDC @ 5A

  • +24VDC Relay @ 0.25A

  • +24VDC Isolated @ 0.125A

• Battery Backup Support: Yes (external battery connection)

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Core power supply for Series 90-30 PLC systems

• Industrial control panels with AC or DC input sources

• Systems requiring CPU memory retention with battery backup

• OEM and distributed control systems

Why Choose the IC693PWR331?

• Dual Input Capability: Accepts AC or DC power sources

• Integrated Battery Port: Enables non-volatile memory retention

• Standard Output Ratings: Powers a full rack of modules reliably

• GE OEM Design: Trusted reliability for critical automation systems

Order Now

The GE Fanuc IC693PWR331 power supply module is available and ready for fast international shipping.
