GE ST-4422

GE Fanuc ST-4422 | Compact 24V DC Digital Output Module for RSTi Systems

Overview

The GE ST-4422 is a high-density 16-point digital output module that delivers 24V DC sourcing (PNP) signals to external actuators and devices. Designed for GE's RSTi (Remote Slice Terminal I/O) system, it provides efficient and reliable output control in compact form, ideal for space-constrained control cabinets in industrial automation environments.

Key Features

• Output Channels: 16 sourcing outputs (PNP)

• Voltage Range: 19.2–28.8 VDC

• Max Output Current: 0.5 A per channel, 4 A per module

• Output Type: Electronic short-circuit protected

• Status Indication: LED indicators for each output channel

• Mounting: DIN rail

• Logic Type: Positive logic

• Built-in Protection: Short circuit, overload, reverse polarity

Technical Specifications

• Model Number: ST-4422

• Nominal Voltage: 24 VDC

• ON-State Voltage Drop: < 1.2 V

• Isolation: Optical isolation between field and logic

• Dimensions (W x H x D): Approx. 12 mm x 99 mm x 70 mm

• Operating Temperature: 0°C to 60°C

• Certifications: CE, UL, cUL, RoHS, Class I Div 2 compliant

Applications

• Controlling solenoids, lights, valves, and relays

• Packaging and assembly lines

• Process automation systems

• Machine control systems

• Distributed I/O for OEM machinery

Why Choose the ST-4422?

• High Channel Density: 16 outputs in a slim footprint

• Reliable Operation: Short-circuit and overload protection

• Diagnostics-Friendly: LED status indicators for fast troubleshooting

• Flexible Integration: Compatible with a wide range of RSTi I/O base modules

• Rugged Design: Built for industrial use in demanding environments

Order Now

The GE ST-4422 16-point digital output module is available and ready to ship.

New:

New product in original sealed packaging. The product may be of an older version or design. Packaging may show markings, discoloration, or signs of wear due to storage.

Refurbished:

Refurbished product fully tested, cleaned, and verified for proper operation. Not in original packaging. The item may show minor cosmetic signs resulting from previous handling or use.

Warranty:

DDPARTSSOLUTION Warranty: 1 Year.

Manufacturer’s warranty and support DO NOT apply.
